Other signals used for HAP mode
Pulse disable The “Pulse disable“ signal deactivates the pulse function in the power source if required.
Pulse range se-
lection
The “Pulse range selection bit 0, bit 1, bit 2“ signal is for setting the pulse frequency range.
Main current (set
value)
By specifying a value between 0 - 65535 (0-100 %), the main current is set to the selected
characteristic.
External parame-
ter (set value)
The “External parameter (set value)“ signal allows a freely definable parameter to be acti-
vated.
IMPORTANT!
The power source operating instructions contain a much more detailed description
of the external parameter, as well as the functions it can perform.
Base current (set
value)
By specifying a value between 0 - 255 (0 % to 100 %), the welding current is reduced to
the base current in HAP pulse mode.
Duty cycle (set
value)
Alters the ratio of pulse duration to base current duration when the pulse frequency has
been selected. Value range 0 - 255 (10 % to 100 %).
Duty cycle disa-
ble
The “Duty cycle disable“ signal deactivates the “Duty cycle (set value)“ function in the pow-
er source if required.
Base current dis-
able
The “Base current disable“ signal deactivates the “Base current (set value)“ function in the
power source if required.
0 0 %
127 50 %
255 100 %
0 0 %
127 40 %
255 100 %
