Fronius TPS/i Robotics TWIN Push - Interconnecting Hosepack; Interconnecting Hosepack-Connections

60
Interconnecting hosepack
Interconnecting
Hosepack—Con-
nections
W = water-cooled interconnecting hosepack
G = gas-cooled interconnecting hosepack
(1) SpeedNet cable
(2) Coolant hoses
(3) Protective gas shield hose
(4) Power cable
(1)
(2)
(3)
(4)
(1)
(4)
(3)
1
2
W
(1)
(3)
(4)
(1)
(4)
(3)
(2)
G
