Fronius TPS/i Robotics TWIN Push - Connecting Wirefeeding Hoses; Threading the Wire Electrode

83
EN-US
1 2
Connecting Wire-
feeding Hoses
1
Connect wirefeeding hoses to the welding wire drums
Threading the
Wire Electrode
CAUTION!
Risk of injury and property damage due to welding current and unintentional igni-
tion of an arc.
► Before starting work, disconnect the ground earth connection between the welding sys-
tem and workpiece.
CAUTION!
Risk of damage to the welding torch due to sharp-edged end of the wire electrodes.
► Thoroughly deburr the end of the wire electrodes before inserting.
CAUTION!
Risk of injury due to spring effect of the coiled wire electrodes.
► When inserting the wire electrodes into the 4 roller drive, keep a secure hold of the end
of the wire electrodes in order to prevent injuries due to wire electrodes springing back.
