70
Connect the inter-
connecting hose-
packs to the
power source,
cooling unit and
TWIN Controller
IMPORTANT! When connecting the interconnecting hosepacks, observe marks 1 and 2
on the interconnecting hosepacks and on the power sources:
1 = water-cooled interconnecting hosepack
2 = gas-cooled interconnecting hosepack
NOTE!
If the interconnecting hosepack is laid incorrectly it can have a significant influence
on the welding results, a stable welding process is not guaranteed!
► As far as possible, maintain a distance of 30 - 50 cm between the two interconnecting
hosepacks.
Lay interconnecting hosepacks to the power sources
Connect the interconnecting hosepacks to the power sources, cooling units and TWIN
Controller
1
