Fronius TransSynergic 5000 - NT 24 - Switched Mode Power Supply 24 V; General Remarks; Component Position in the Machine; Overview

59
EN
NT 24 - switched mode power supply 24 V
General remarks NT 24 switched mode power supply (item number 4,070,626,Z) for internal and external
components.
Important! On NT 24 switched mode power supply, the primary voltage is on!
Component
position in the
machine
Fig. 24 TPS 2700, position of NT 24
Fig. 26 NT 24
Overview
Fig. 25 TPS 3200, TS/TPS 4000/5000:
Position of NT 24
Primary voltage
Secondary voltage
X2
X1
LED 24 V internal LED 15 V primary
LED 24 V external
