Scan
4
4 Scan
172
The following are examples:
z
For [FTP]:
Server name: myhost.example.com
(myhost: host name, example.com: domain name)
IP address: 192.0.2.1
z
For [SMB]:
Server name: myhost
IP address: 192.0.2.1
îš„Shared Name
This option is displayed when you select [SMB] in [Transfer Protocol]. Enter a shared
name. When the save location is in the DFS namespace on Windows, enter a root
name. Up to 64 characters are allowed.
îš„Save in
This option is displayed when you select [FTP] or [SMB] in [Transfer Protocol]. Enter a
directory path. When the save location is in the DFS namespace on Windows, enter a
folder name. Up to 128 characters are allowed.
Note • The folder name is the same as the link name for Windows Server 2003.
z
For [FTP]:
Example: mydoc/Scan
z
For [SMB]:
Example: mydoc\Scan
îš„Save in
This option is displayed when you select [SMB (UNC Format)] in [Transfer Protocol].
Enter the following directory path: "\\Host Name\Shared Name\Directory Name". When
the save location is in the DFS namespace on Windows, enter "\\Domain Name\Root
Name\Folder Name" or "\\Server Name\Root Name\Folder Name". Up to 260
characters are allowed.
îš„User Name
Enter the user name of the computer you are forwarding to. When a user name is not
required for the destination, this field can be skipped.
When you select [FTP] in [Transfer Protocol], up to 97 characters are allowed.
When you select [SMB] in [Transfer Protocol], use one of the following formats:
z
For Active Directory:
User name@Domain name (user name: up to 32 characters, domain name: up to 64
characters)
Example: fuji@example.com (fuji: user name, example.com: domain name)
z
For Windows NT Domain:
Domain name\User name (domain name: up to 64 characters, user name: up to 32
characters)
Example: example\fuji (example: domain name, fuji: user name)
z
For workgroups:
Local user (up to 32 characters)
Example: Fuji-Taro
To Next Page
