Specifications
515
Appendix
15
îš„Duplex Automatic Document Feeder
îš„Duplex Output Unit
îš„Finisher-A1 (Optional)*
Type Duplex automatic document feeder
Original Paper Size Maximum: A3, 11 × 17" (279 × 432 mm)
Minimum : A5, 38 - 128 gsm
(2 sided: 50 - 128 gsm)
Capacity 110 sheets (A4 1 sided)
Important • When using 80 gsm paper
Feeding Speed Monochrome : 20 sheets/minute (A4 1 sided)
Color : 20 sheets/minute (A4 1 sided)
Dimensions/Weight Width 540 × Depth 492 × Height 105 mm (to the top cover of the
document feeder)
Width 540 × Depth 492 × Height 125 mm (to the protruding
portion of the document feeder tray)
7.3 kg
Applicable Paper Size Same as the Copy Function
Paper weight 60 - 169 gsm
Type Finisher tray : Sorting (Offset available)/
Stacking (Offset available)
Paper Size/Paper
Weight
Finisher tray Maximum: A3, 11 × 17"
Minimum: Postcards (100 × 148mm),
60 - 220 gsm
Stacker Capacity Finisher tray (For paper not stapled)
A4: 500 sheets, B4: 250 sheets,
A3 or larger: 200 sheets, Mixed stack*: 250 sheets
(For paper stapled)
30 sheets
*: Based on when larger size paper is stacked on paper.
Important • When using 80 gsm paper
Staple Capacity: A4: 50 sheets (90 gsm or less),
B4 or larger: 30 sheets (90 gsm or less)
Paper Size: Maximum: A3, 11 × 17", Minimum: B5
Position: 1 place (front/angled stapling)
Important • When using 80 gsm paper
Dimensions/Weight Width 559 × Depth 448 × Height 246 mm, 12 kg
Space Requirement
(when connected to the
main unit)
Width 1,039 × Depth 640 mm (main unit + Finisher-A1, when the
extension tray and the bypass tray are fully extended)
To Next Page
