Replacing Consumables
59
Maintenance
3
• The use of waste toner containers not recommended by Fuji Xerox may degrade image
quality and performance. Use only waste toner containers recommended by Fuji Xerox.
1 Make sure that the machine is not operating,
and open the front cover.
2 While holding down the tabs on the top of
the waste toner container, lay the container
down toward you and then pull out the
container upward at an angle.
Important • After removing the waste toner container
from the machine, do not turn the
container upside down. Otherwise, toner
may spill.
3 Prepare a new waste toner container and
cleaning bar.
Note • Take a new container and cleaning bar
out of the box in advance.
4 Clean each of the laser scanners once with
the new cleaning bar.
Insert the cleaning bar into each slot until it
stops, and then slowly slide the bar back out.
Waste Toner Container
To Next Page
