3 Maintenance
60
Maintenance
3
5 After cleaning the laser scanners, remove
the old cleaning bar from the back side of the
front cover.
6 Attach the new cleaning bar to the back side
of the front cover.
7 Align the dents at the bottom of the waste
toner container with the tabs on the machine.
8 Raise the waste toner container toward the
inside of the machine until it clicks into place.
9 Insert the used waste toner container into
the supplied plastic bag.
To Next Page
