6.2 Stapler Faults 241
Staple Jams in Finisher-B1
This section describes how to clear staple jam occurred in the staple cartridge of the
Finisher-B1 (optional).
When Staple Jams occurs in Staple Cartridge (R1)
1. Make sure that the machine is not
operating, and open the front door.
2. Grasp the handle R1 as shown in the
illustration to pull out the staple cartridge to
the right, towards you.
3. Move up the staple cartridge, and then take
it out of the machine.
Note
• The staple cartridge is firmly inserted. A slight force is
required to pull the cartridge out of the finisher.
4. After you take out the staple cartridge,
check inside of the finisher for any
remaining staples.
To Next Page
