A.8 Installing the Parallel Port Kit 417
A.8 Installing the Parallel Port Kit
This section describes how to install the Parallel Port Kit on the printer.
Note
• The clamp that come with the option are not used with this printer.
Important
• Parallel Port Kit and Gigabit Ethernet Board Kit cannot be installed concurrently. If the Gigabit Ethernet
Board Kit is installed, remove the card by reference to “Removing the Gigabit Ethernet Board Kit”
(P. 425).
Installing the Parallel Port Kit
1. Press the < > side of the printer's power
switch to turn off the power.
Note
• Make sure that there is no indication on the display,
and <Energy Saver> button is off.
2. Open the front cover.
Parallel Port Kit (with frame) Connector conversion cable
To Next Page
