6.2 Stapler Faults 243
Staple Jams in Booklet Maker Unit for Finisher-B1
This section describes how to clear staple jam occurred in the staple cartridge of the Booklet
Maker Unit for Finisher-B1 (optional).
When Stale Jams occurs in Staple Cartridge R2 / R3
1. Make sure that the machine is not
operating, and open the booklet maker side
cover.
2. With holding the tabs on both sides of the
booklet staple cartridge, lift the booklet
staple cartridge out of the unit.
3. After you take out the booklet staple
cartridge, check inside of the Booklet Maker
Unit for any remaining staples.
4. With holding the tabs, return the cartridge
to the original position, and then gently
push the cartridge in until it clicks into
place.
5. Make sure another booklet staple cartridge
in the same way.
6. Close the booklet maker side cover.
Note
• If the booklet maker side cover is not completely
closed, a message will appear and the machine
remains paused.
To Next Page
