420 A Appendix
Refer to
• List printing procedure: “Printing a Report/List” (P. 329)
Parallel Port Kit installation is now complete.
Removing the Parallel Port Kit
This section describes how to remove the Parallel Port Kit on the printer. Refer to the steps
in the “Installing the Parallel Port Kit” (P. 417) above for the detailed instructions as the
similar steps are explained simply.
1. Press the < > side of the printer's power
switch to turn off the power.
Note
• Make sure that there is no indication on the display,
and <Energy Saver> button is off.
2. Open the front cover.
3. Press the < > side of the printer's main
power switch to turn off the main power and
close the front cover.
Note
• The <Main Power> lamp goes out on the control
panel.
4. Unplug the power cord from the power
outlet and the printer.
5. Loosen the three screws on the control
board of the printer.
screw
To Next Page
