54 2 Basic Operation
Control Panel
No. Name Description
1 <Log In/Out> lamp Lights when authenticating the card that is inserted in the Embedded IC Card
Reader (optional) or the connected IC Card Reader for relative devices.
2 <Ready> lamp Lights when the printer is ready to print.
3 <Error> lamp Blinks or lights when an error occurs.
4 <Main Power> lamp Lights when the main power of the printer is switched on.
5 Display Displays the status of the printer, menu options, and messages.
[Please Wait...] is displayed when the printer power is switched on. Print job is
available when the display message changes to [Ready to print].
It displays authenticated user ID for about 2 seconds when card authentication
is used.
Nothing will be displayed during Energy Saver Mode even if the printer power is
switched on.
Refer to
• “Control Panel Display” (P. 56)
6 <Energy Saver> button The button lights while the printer is in Energy Saver mode.
The printer exits Energy Saver mode by pressing this button.
The printer enters Energy Saver mode (Low Power mode) by pressing this
button during Stand-by state.
Note
• <Energy Saver> button may be kept lit for several tens of seconds if the
printer is switched off during Energy Saver mode.
7 Toner Color Display Shows the color of the remaining toner appears on the display.
8
7
2
1
4
6
5
3
9
10
11
12
13
14
15
16
To Next Page
