246 6 Troubleshooting
When Staple Jams occurs in Booklet Staple Cartridge R2 / R3
This section describes how to clear staple jam occurred in the booklet staple cartridge of
the Finisher-C1 with Booklet Maker (optional).
1. Make sure that the machine is not
operating, and open the front door.
2. While pressing the handle to the right, take
the staple cartridge unit out of the machine.
3. Hold the tabs on both sides of the booklet
staple cartridge.
4. Rotate the booklet staple cartridge at an
angle.
5. Lift the booklet staple cartridge out of the
unit.
To Next Page
