302 7 Maintenance
3. Lower the cover.
Note
• You can now see the drum cartridge.
4. Slowly slide out the cleaning bars housed
within the LED printhead until it stops. The
cleaning bars are located in the cleaning
connection just under the drum cartridges
(R1, R2, R3, or R4).
Note
• Slide out the cleaning bars until you see "zzz.”
Important
• Do not remove the cleaning bars from the housing.
5. Slowly slide the cleaning bars back into
place.
Note
• Clean the four LED printheads (R1 to R4) by sliding
the cleaning bars back and fourth for two or three
times, respectively.
6. Return the cover to the original position.
Note
• Push the cover until it clicks into place.
7. Rotate the release lever clockwise to lock
the cover.
To Next Page
