7.1 Replacing Consumables 315
5. Hold the fusing unit by the grips on both
sides, and remove the fusing unit from the
machine.
Important
• The fusing unit weights approximately 4 kg. Be careful
not to drop the unit.
6. Take out a new fusing unit from the box.
7. Hold the new fusing unit by the grips on
both sides, and then place the fusing unit
onto the machine.
Important
• Hold the fusing unit with both hands so that you do not
drop it.
8. While holding the fusing unit with one hand,
tighten the screws on both sides with the
other hand.
9. Push the center of the upper left cover A
and close the cover gently, and then close
Tray 5.
10. Switch on the power.
Refer to
• For information on how to switch on the power and the
main power, refer to “2.2 Switching On/Off the Power”
(P. 57).
To Next Page
