7.1 Re
placi
ng Cons
uma
bles
325
6.
Press the <OK> button.
7.
This resets the counter for the Paper Feed
Rolls.
8.
Press the <Settings> button to close the
menu.
Resetting Fus
er
2ndBiasTrans.
Roll
Resetcomplete
dfor
2ndBiasTrans.
Roll
324
326
Table of Contents
Table of Contents
5
Default Chapter
3
Preface
3
Docuprint C5005 D Features
4
Table of Contents
5
Contents
5
Types of Manuals
10
Using this Guide
11
Safety Notes
13
Electrical Safety
14
Machine Installation
15
Operational Safety
16
Warning and Caution Labels
19
Licenses
21
Illegal Copies and Printouts
26
1 Printer Environment Settings
27
Supported Operating Environments
27
Connecting a Cable
30
Network Connection
32
Parallel Connection
33
Switching the Control Panel Display Language
35
Setting the Network Environment
36
Setting an IP Address (Ipv4)
36
Setting an IP Address (Ipv6)
39
Enabling Ports
40
Configuring the Printer Using Centreware Internet Services
41
Overview of Centreware Internet Services
41
Setting up the Printer
42
Centreware Internet Services Settings
43
Using Centreware Internet Services
44
Using the Online Help
45
Installing a Print Driver
46
2 Basic Operation
47
Main Components and Functions
47
Main Unit
47
Control Panel
54
Control Panel Display
56
Switching On/Off the Power
57
Switching the Main Power on
57
Switching the Power on
57
Switching the Power off
58
Switching the Main Power off
59
Circuit Breaker
60
Setting/Exiting the Energy Saver Modes
62
Entering the Energy Saver Modes
62
Exiting the Energy Saver Modes
62
If the Printer Does Not Enter Energy Saver Mode
62
Canceling/Checking a Print Job
63
Canceling a Print Job
63
Checking the Status of a Print Job
64
Importing Printer Information to a Print Driver
65
Obtain Printer Information by Specifying Printer Name and IP Address
65
Obtain Printer Information Automatically
67
Set Printer Information Manually
68
3 Printing
70
Printing from a Computer
70
Printing on Envelopes
72
Loading Envelopes
72
Printing on Envelopes
73
Printing on Custom Size or Long-Size Paper
76
Loading Custom Size or Long Size Paper
76
Registering Custom Size Paper
77
Printing on Custom Size Paper
80
Printing Various Types of Papers
81
Printing Confidential Documents - Secure Print
83
Printing with Secure Print
83
Printing after Checking Output - Sample Set
87
Printing Using Sample Set
87
Printing at a Specified Time - Delayed Print
91
Registering a Delayed Print Job
91
Canceling a Delayed Print Job
92
Private Charge Print
94
Configuring Private Charge Print Settings
94
Deleting Print Job
95
Printing with Private Charge Print
95
Charge Print
96
Configuring Charge Print Settings
96
Printing with Charge Print
97
Direct Printing of PDF Files
99
Printing PDF Files Directly
99
Supported PDF Files
99
Direct Printing of Docuworks Files
101
Printing Docuworks Files Directly
101
Supported Docuworks Files
101
Printing Using E-Mail - Mail Print
103
Configuring the Mail Print Environment
103
Receiving E-Mails
108
Receiving and Printing E-Mail Manually
109
Precautions When Using Mail Print
110
4 Paper
111
About Paper
111
Supported Paper Type
111
Supported Paper Type
113
Usable Paper
115
Special Media
117
Unsupported Paper
119
Storing and Handling Paper
120
Loading Paper
121
Loading Paper in the Bypass Tray
121
Loading Paper into Trays 1 through 4
124
Loading Paper into Tray 3
125
Loading Paper into Tray 4
125
Loading Paper into Tray 6 (HCF B1)
126
Paper Sizes/Paper Type for Trays 1 through 4
126
Setting the Paper Sizes of Trays
129
Changing the Paper Type Settings of Trays
131
Configuring Image Quality Settings for each Paper Type
132
Auto Tray Selection Feature
133
Setting Tray 5 (Bypass) for Auto Tray Selection
134
5 Control Panel Settings
136
Overview of the Common Menus
136
Menu Structure
136
Changing the Settings
138
Common Menus Setting
140
[Languageemulation]
140
[Meter Reading]
146
[Print Reports]
146
[Admin Menu]
147
Port 9100
157
Dns Server
162
Wins Server
165
System Settings
170
Auto Clear
171
Low Power Mode
171
Low Power Timer
172
Sleep Mode
172
Driver Settings
174
Sided Report
174
Machine Clock
176
Print Speed
177
Data Encryption
179
Software Download
180
Ram Disk
181
Stored Jobs
185
Software Options
186
Software Upgrade
188
Paper Type
191
Paper Color
192
Paper Size Group
202
Image Quality
208
6 Troubleshooting
215
Clearing Paper Jams
215
Paper Jam in Tray 5
216
Paper Jam in Trays 1 to 4
217
Paper Jam in Tray 3
217
Paper Jams in Tray 6 (HCF B1)
220
Paper Jams in Upper Left Cover a
223
Paper Jams in Bottom Left Cover C
225
Paper Jams in Top Left Cover D
226
Paper Jams in Duplex Module Cover B
228
Paper Jams in Finisher-B1
229
Paper Jams under the Finisher Top Cover
229
Paper Jams in Finisher-C1 with Booklet Maker
231
Paper Jams in the Finisher Transport Cover
231
Paper Jams at 2A in the Finisher
232
Paper Jams at 2B in the Finisher
233
Paper Jams at 3 in the Finisher
235
Paper Jams at 4A in the Finisher
236
Paper Jams at 4B in the Finisher
237
Paper Jams in the Right Bottom Tray
239
Stapler Faults
240
Staple Jams in Finisher-B1
241
Staple Jams in Booklet Maker Unit for Finisher-B1
243
Staple Jams in Finisher-C1 with Booklet Maker
244
Hardware Problems (Power Failure, Abnormal Noise, Etc.)
248
Printing Problems
249
Print and Image Quality Problems
251
Clearing the Interior (LED Printheads) of the Printer
255
Paper Feed Problems
257
Error Messages and Error Codes
258
Error Messages (in Alphabetical Order)
258
Error Codes
270
Network-Related Problems
287
Centreware Internet Services Problems
287
Mail Print/E-Mail Notification Service Problems
288
Ipv6 Connection Problems
289
Ipv6 Environment Printing Problems
289
Other Ipv6 Problems
290
Non-Genuine Mode
291
7 Maintenance
292
Replacing Consumables
292
Types of Consumables
292
Recycling Used Consumables
293
Replacing Toner Cartridges
294
Replacement Procedure
295
Replacing Drum Cartridges
297
Replacing the Waste Toner Bottle
301
Replacing Staple Cartridge
305
Emptying the Punch Waste Container
311
Replacing the Fusing Unit
314
Replacing the 160K Maintenance Kit
317
Replacing the 200K Maintenance Kit
322
Printing Reports/Lists
326
Types of Reports/Lists
326
Printing a Report/List
329
Checking the Meter Reading
330
Checking the Meter Reading by Output Color (Meter)
330
Checking the Meter Reading by Computer ([Meter Report (Print Jobs)])
331
Checking the Meter Reading by Function ([Job Counter Report])
332
Changing an IP Address
333
Monitoring/Managing the Printer with a Web Browser
336
Checking Printer Status Via E-Mail
337
Configuring the E-Mail Notification Service
337
Information Reported by the E-Mail Notification Service
337
Checking Machine Serial Number
340
Enabling a RAM Disk
341
Security Features
343
Security Feature Overview
343
Controlling Data Reception by IP Address
345
Using the Watermark Feature
346
Secure Watermark
348
Print Universal Unique ID
350
Force Annotation Feature
351
Using the Audit Log
353
Stored Information in the Audit Log
355
Configuring Encryption Settings
356
About Encryption
356
Types of Certificate
356
Configuring HTTP Communication Encryption Settings
358
Configuring Ipsec for Encryption
361
Configuring Ipsec Settings
363
Control Access to Printer Features by Pre-Registering Users
365
Overview of Authentication and Auditron Administration Feature
365
Configuring Authentication and Auditron Administration Settings
366
Configuration for IC Card Reader (Optional)
371
Adjusting Tone Density
373
Calibration Procedure
373
Performing Calibration
374
Adjusting the Image Transfer Voltage
380
Adjusting the Paper Regi
382
Cleaning the Printer
385
Cleaning the Exterior of the Printer
385
Moving the Printer
386
A Appendix
387
Docuprint C5005 D Specifications
387
Main Specifications
387
Finisher-B1 (Optional)
395
Finisher-C1 with Booklet Maker (Optional)
396
Left Top Tray (Optional)
398
Tray 6 (HCF B1)(Optional)
398
Built-In Fonts
399
Printable Area
399
A.2 Options
401
Options
401
Life of Consumables and Regular Replacement Parts
402
Regular Replacement Parts
403
Obtaining Product Information
404
Obtaining the Latest Print Driver Version
404
Updating the Printer's Firmware
404
Installing Extension System Memory
405
Procedure for Installing Extension System Memory
407
Installation Procedure
410
Installing the HDD Extension Kit
410
Installation Procedure
413
Installing the Feature Enhance Kit
413
Installing the Parallel Port Kit
417
Removing the Parallel Port Kit
420
Installing the Gigabit Ethernet Board Kit
422
Removing the Gigabit Ethernet Board Kit
425
Installation Procedure
427
Installing the TC/SC Additional Fonts Kit
427
Notes and Restrictions
430
Notes and Restrictions on Using the Printer
430
Postscript Driver
431
Xps Driver
431
Ipp Print
432
TCP/IP (Lpd) Note and Limitations
434
Pv6 Connection Notes and Limitations
436
Notes and Restrictions on the Cloning Feature
437
Notes and Restrictions on Security Features
439
Allow User to Disable Active Settings
440
Glossary
442
Full Color
443
Image Enhancement
443
Interface Cable
444
Network Printer
444
Online Help
445
Parallel Interface
445
Print Driver
445
Receive Buffer
445
Web Browser
446
Index
447
Control Panel Menu Tree
452
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Fuji Xerox DocuPrint C5005 d and is the answer not in the manual?
Ask a question
Fuji Xerox DocuPrint C5005 d Specifications
General
Brand
Fuji Xerox
Model
DocuPrint C5005 d
Category
Printer
Language
English
Related product manuals
Fuji Xerox DocuPrint CP405 d
306 pages
Fuji Xerox DocuPrint CP305 d
299 pages
Fuji Xerox DocuPrint P355 d
272 pages
Fuji Xerox DocuPrint P255 d
252 pages
Fuji Xerox DocuPrint P225 d
2 pages
Fuji Xerox DocuPrint P455 D
302 pages
Fuji Xerox DocuPrint P365 d
217 pages
Fuji Xerox DocuPrint P505 d
279 pages
Fuji Xerox DocuPrint P375 d
301 pages
Fuji Xerox DocuPrint CM225FW
344 pages
Fuji Xerox DocuPrint CM315 z
2 pages
Fuji Xerox DocuPrint CM305 df
527 pages
Need help?
General
To Next Page
