COOLING CAPACITY
TC : Total Capacity kW.
IP : Input Power kW (Compressor + Outdoor fan motor).
The data is based on the following conditions. Pipe length : 7.5m , Height difference : 0m.
CAPACITY TABLE COOLING (OUTDOOR UNIT)4.
MODEL : AJ
A40LALH
Capacity : 12.1 kW (4HP)
z
Total rated
cooling capacity
of indoor unit
Outdoor
temperature
Indoor temperature
20°CDB / 15 °CWB 23°CDB / 16 °CWB 24°CDB / 17 °CWB 26°CDB / 18 °CWB 27°CDB / 19 °CWB 28°CDB / 20 °CWB 30°CDB / 22 °CWB 32°CDB / 23 °CWB
(°CDB) TC IP TC IP TC IP TC IP TC IP TC IP TC IP TC IP
15.7
(130%)
10
10.4 1.73 11.7 1.94 13.0 2.15 14.4 2.36 15.7 2.57 17.0 2.76 17.7 2.80 18.1 2.82
15
10.4 1.73 11.7 1.94 13.0 2.15 14.4 2.36 15.7 2.57 16.9 2.84 17.5 2.92 17.9 2.96
21
10.4 1.77 11.7 2.07 13.0 2.39 14.4 2.74 15.7 3.11 16.3 3.22 16.9 3.29 17. 2 3.33
23
10.4 1.88 11.7 2.20 13.0 2.54 14.4 2.91 15.7 3.30 16.1 3.35 16.7 3.42 17. 0 3.45
25
10.4 2.00 11.7 2.33 13.0 2.70 14.4 3.09 15.6 3.44 15.9 3.47 16.5 3.54 16.8 3.58
27
10.4 2.12 11.7 2.48 13.0 2.86 14.4 3.27 15.4 3.56 15.7 3.60 16.3 3.67 16.6 3.70
30
10.4 2.31 11.7 2.70 13.0 3 .12 14.4 3.57 15.1 3.75 15.4 3.79 16.0 3.85 16.3 3.89
33
10.4 2.51 11.7 2.93 13.0 3.39 14.4 3.88 14.8 3.94 15.1 3.97 15.7 4.04 16.0 4.07
35
10.4 2.65 11.7 3.10 13.0 3.58 14.2 4.04 14.6 4.08 14.9 4.11 15.5 4.19 15.8 4.23
37
10.4 2.80 11.7 3.27 13.0 3.80 14.0 4.19 14.4 4.23 14.7 4.27 15.3 4.35 15.6 4.38
40
10.4 3.04 11.7 3.58 13.0 4.16 13.8 4.42 14.1 4.46 14.4 4.50 15.0 4.58 15.3 4.62
43
10.4 3.32 11.7 3.91 13.0 4.54 13.5 4.65 13.8 4.70 14.1 4.74 14.7 4.82 15.0 4.86
46
10.4 3.62 11.7 4.26 12.1 4.50 12.3 4.50 12.5 4.50 12.7 4.50 13.1 4.50 13.3 4.50
14.5
(120%)
10
9.56 1.60 10.8 1.80 12.0 1.99 13.3 2 .19 14.5 2.38 15.8 2.58 17.3 2.78 17.7 2.80
15
9.56 1.60 10.8 1.80 12.0 1.99 13.3 2 .19 14.5 2.38 15.8 2.58 17. 2 2.88 17.5 2.92
21
9.56 1.64 10.8 1.86 12.0 2.15 13.3 2.45 14.5 2.77 15.8 3.12 16.6 3.26 16.9 3.29
23
9.56 1.70 10.8 1.98 12.0 2.28 13.3 2.60 14.5 2.95 15.8 3.31 16.4 3.38 16.7 3.42
25
9.56 1.81 10.8 2.11 12.0 2.42 13.3 2.76 14.5 3.13 15.6 3.44 16.2 3.51 16.5 3.54
27
9.56 1.92 10.8 2.23 12.0 2.57 13.3 2.93 14.5 3.32 15.4 3.57 16.0 3.63 16.3 3.67
30
9.56 2.09 10.8 2.43 12.0 2.80 13.3 3.19 14.5 3.61 15.1 3.75 15.7 3.82 16.0 3.85
33
9.56 2.27 10.8 2.65 12.0 3.05 13.3 3.47 14.5 3.91 14.8 3.94 15.4 4.01 15.7 4.04
35
9.56 2.40 10.8 2.80 12.0 3.22 13.3 3.67 14.3 4.04 14.6 4.08 15.2 4.15 15.5 4.19
37
9.56 2.53 10.8 2.95 12.0 3.40 13.3 3.90 14.1 4.20 14.4 4.24 15.0 4.31 15.3 4.35
40
9.56 2.75 10.8 3.22 12.0 3.72 13.3 4.27 13.8 4.43 14.1 4.47 14.7 4.55 15.0 4.58
43
9.56 3.00 10.8 3.51 12.0 4.06 13.2 4.62 13.5 4.66 13.8 4.70 14.4 4.78 14.7 4.82
46
9.56 3.27 10.8 3.83 12.0 4.43 12.3 4.50 12.4 4.50 12.6 4.50 13.0 4.50 13.2 4.50
13.3
(110%)
10
8.76 1.48 9.90 1.66 11.0 1.84 12.2 2.01 13.3 2 .19 14.4 2.37 16.7 2.73 17.2 2.78
15
8.76 1.48 9.90 1.66 11.0 1.84 12.2 2.01 13.3 2 .19 14.4 2.37 16.7 2.82 17.1 2.87
21
8.76 1.51 9.90 1.69 11.0 1.92 12.2 2.18 13.3 2.46 14.4 2.75 16.2 3.21 16.5 3.25
23
8.76 1.57 9.90 1.78 11.0 2.04 12.2 2.32 13.3 2.61 14.4 2.93 16.0 3.34 16.3 3.38
25
8.76 1.63 9.90 1.89 11.0 2.16 12.2 2.46 13.3 2.77 14.4 3.11 15.8 3.47 16 .1 3.50
27
8.76 1.73 9.90 2.00 11.0 2.30 12.2 2.61 13.3 2.94 14.4 3.29 15.6 3.59 15.9 3.63
30
8.76 1.88 9.90 2.18 11.0 2.50 12.2 2.84 13.3 3.20 14.4 3.59 15.3 3.78 15.6 3.82
33
8.76 2.04 9.90 2.37 11.0 2.72 12.2 3.09 13.3 3.49 14.4 3.91 15.1 3.97 15.4 4.00
35
8.76 2.16 9.90 2.51 11.0 2.87 12.2 3.27 13.3 3.68 14.3 4.04 14.9 4.11 15.2 4.15
37
8.76 2.28 9.90 2.65 11.0 3.04 12.2 3.45 13.3 3.91 14.1 4.20 14.7 4.27 15.0 4.31
40
8.76 2.47 9.90 2.87 11.0 3.31 12.2 3.78 13.3 4.28 13.8 4.43 14.4 4.51 14.7 4.54
43
8.76 2.69 9.90 3.14 11.0 3.61 12.2 4.13 13.2 4.62 13.5 4.66 14.1 4.74 14.4 4.78
46
8.76 2.93 9.90 3.42 11.0 3.94 12.2 4.50 12.3 4.50 12.4 4.50 12.8 4.50 13.0 4.50
12 .1
(100%)
10
7.9 6 1.36 9.00 1.52 10.0 1.68 11.1 1.84 12.1 2.00 13.1 2.16 15.2 2.49 16.2 2.65
15
7.9 6 1.36 9.00 1.52 10.0 1.68 11.1 1.84 12.1 2.00 13.1 2.16 15.2 2.49 16.2 2.70
21
7.9 6 1.38 9.00 1.55 10.0 1.71 11.1 1.92 12.1 2.16 13.1 2.41 15.2 2.96 16.1 3.20
23
7.9 6 1.44 9.00 1.61 10.0 1.81 11.1 2.05 12.1 2.30 13.1 2.57 15.2 3.15 15.9 3.33
25
7.9 6 1.49 9.00 1.68 10.0 1.92 11.1 2.17 12.1 2.44 13.1 2.72 15.2 3.34 15.7 3.46
27
7.9 6 1.55 9.00 1.78 10.0 2.04 11.1 2.30 12.1 2.59 13.1 2.89 15.2 3.54 15.5 3.58
30
7.9 6 1.68 9.00 1.94 10.0 2.22 11.1 2.51 12.1 2.82 13.1 3.15 14.9 3.74 15.2 3.77
33
7.9 6 1.83 9.00 2.11 10.0 2.41 11.1 2.73 12.1 3.07 13 .1 3.42 14.7 3.93 15.0 3.96
35
7.9 6 1.93 9.00 2.23 10.0 2.55 11.1 2.89 12.1 3.25 13.1 3.62 14.5 4.07 14.8 4.10
37
7.9 6 2.03 9.00 2.35 10.0 2.69 11.1 3.05 12.1 3.42 13.1 3.84 14.3 4.22 14.6 4.26
40
7.9 6 2.20 9.00 2.55 10.0 2.92 11.1 3.32 12.1 3.75 13.1 4.20 14.0 4.46 14.3 4.50
43
7.9 6 2.39 9.00 2.78 10.0 3.19 11.1 3.63 12.1 4.09 13.1 4.59 13.7 4.69 14.0 4.73
46
7.9 6 2.61 9.00 3.03 10.0 3.48 11.1 3.96 12.1 4.47 12.4 4.50 12.7 4.50 12.9 4.50
10.8
(90%)
10
7.17 1.23 8 .10 1.38 9.03 1.52 10.0 1.67 10.8 1.81 11.8 1.96 13.7 2.25 14.6 2.40
15
7.17 1.23 8 .10 1.38 9.03 1.52 10.0 1.67 10.8 1.81 11.8 1.96 13.7 2.25 14.6 2.40
21
7.17 1.25 8 .10 1.40 9.03 1.55 10.0 1.70 10.8 1.89 11.8 2 .10 13.7 2.55 14.6 2.80
23
7.17 1.30 8.10 1.46 9.03 1.61 10.0 1.79 10.8 2.00 11. 8 2.23 13.7 2.71 14.6 2.97
25
7.17 1.35 8.10 1.51 9.03 1.69 10.0 1.90 10.8 2.13 11.8 2.37 13.7 2.88 14.6 3.16
27
7.17 1.40 8.10 1.57 9.03 1.79 10.0 2.02 10.8 2.26 11.8 2.51 13.7 3.05 14.6 3.35
30
7.17 1.49 8 .10 1.71 9.03 1.95 10.0 2.20 10.8 2.46 11.8 2.73 13.7 3.33 14.6 3.65
33
7.17 1.62 8.10 1.86 9.03 2.12 10.0 2.39 10.8 2.68 11.8 2.97 13.7 3.62 14.5 3.91
35
7.17 1.71 8.10 1.97 9.03 2.24 10.0 2.53 10.8 2.83 11.8 3.14 13.7 3.83 14.3 4.05
37
7.17 1.80 8.10 2.08 9.03 2.36 10.0 2.67 10.8 2.98 11. 8 3.32 13.7 4.07 14.1 4.20
40
7.17 1.95 8.10 2.25 9.03 2.56 10.0 2.90 10.8 3.25 11.8 3.63 13.6 4.40 13.9 4.44
43
7.17 2.11 8.10 2.44 9.03 2.79 10.0 3 .16 10.8 3.55 11.8 3.97 13.3 4.64 13.6 4.68
46
7.17 2.30 8.10 2.66 9.03 3.04 10.0 3.44 10.8 3.87 11.8 4.32 12.3 4.50 12.5 4.50
