Fujitsu Airstage J-II User Manual

HEATING CAPACITY
TC : Total Capacity kW.
FLOOR / CEILING TYPE8-7.
MODEL : AB
 
A12GATH
MODEL : AB
 
A14GATH
MODEL : AB
 
A18GATH
MODEL : AB
 
A24GATH
Outdoor Temperature
Indoor temperature
16°CDB 18°CDB 20°CDB 21°CDB 22°CDB 24°CDB 26°CDB
(°CDB)
(°CWB) TC TC TC TC TC TC TC
-19.3
-20.0
4.2 4.1 4.1 4.1 4.1 4.1 4.1
-15.0
-16.0
4.8 4.8 4.8 4.8 4.8 4.7 4.7
-12.0
-13.0
5.4 5.3 5.3 5.3 5.3 5.3 5.2
-9.0
-10.0
5.9 5.9 5.8 5.8 5.8 5.8 5.7
-7.0
-8.0
6.2 6.2 6.2 6.2 6.1 6.1 6.1
-5.0
-6.0
6.6 6.6 6.6 6.5 6.5 6.5 6.3
-3.0
-4.0
7.0 6.9 6.9 6.9 6.9 6.8 6.3
-1.0
-2.0
7.4 7. 3 7. 3 7. 2 7. 2 6.9 6.3
0.0
-1.0
7.5 7. 5 7.4 7.4 7.4 6.9 6.3
2.0
1.0
7.9 7. 9 7. 8 7.7 7.4 6.9 6.3
5.0
4.0
8.5 8.5 8.0 7.7 7. 5 6.9 6.4
7.0
6.0
8.9 8.5 8.0 7.7 7. 5 6.9 6.4
9.0
7.8
9.1 8.5 8.0 7.7 7.5 6.9 6.4
12.0
10.6
9.1 8.5 8.0 7.7 7.5 6.9 6.4
15.0
13.5
9.1 8.5 8.0 7.7 7.5 6.9 6.4
Outdoor Temperature
Indoor temperature
16°CDB 18°CDB 20°CDB 21°CDB 22°CDB 24°CDB 26°CDB
(°CDB)
(°CWB) TC TC TC TC TC TC TC
-19.3
-20.0
3.3 3.3 3.3 3.3 3.2 3.2 3.2
-15.0
-16.0
3.8 3.8 3.8 3.8 3.8 3.7 3.7
-12.0
-13.0
4.2 4.2 4.2 4.2 4.2 4.1 4.1
-9.0
-10.0
4.6 4.6 4.6 4.6 4.6 4.5 4.5
-7.0
-8.0
4.9 4.9 4.9 4.9 4.8 4.8 4.8
-5.0
-6.0
5.2 5.2 5.2 5.1 5.1 5 .1 5.0
-3.0
-4.0
5.5 5.5 5.4 5.4 5.4 5.4 5.0
-1.0
-2.0
5.8 5.8 5.7 5.7 5.7 5.4 5.0
0.0
-1.0
5.9 5.9 5.9 5.8 5.8 5.4 5.0
2.0
1.0
6.2 6.2 6.2 6.0 5.8 5.4 5.0
5.0
4.0
6.7 6.7 6.3 6.1 5.9 5.5 5.0
7.0
6.0
7.0 6.7 6.3 6 .1 5.9 5.5 5.0
9.0
7.8
7.1 6.7 6.3 6.1 5.9 5.5 5.0
12.0
10.6
7.1 6.7 6.3 6.1 5.9 5.5 5.0
15.0
13.5
7.1 6.7 6.3 6.1 5.9 5.5 5.0
Outdoor Temperature
Indoor temperature
16°CDB 18°CDB 20°CDB 21°CDB 22°CDB 24°CDB 26°CDB
(°CDB)
(°CWB) TC TC TC TC TC TC TC
-19.3
-20.0
2.6 2.6 2.6 2.6 2.6 2.6 2.6
-15.0
-16.0
3.0 3.0 3.0 3.0 3.0 3.0 3.0
-12.0
-13.0
3.3 3.3 3.3 3.3 3.3 3.3 3.3
-9.0
-10.0
3.7 3.7 3.6 3.6 3.6 3.6 3.6
-7.0
-8.0
3.9 3.9 3.9 3.9 3.8 3.8 3.8
-5.0
-6.0
4.1 4.1 4.1 4.1 4.1 4.0 3.9
-3.0
-4.0
4.4 4.3 4.3 4.3 4.3 4.3 4.0
-1.0
-2.0
4.6 4.6 4.5 4.5 4.5 4.3 4.0
0.0
-1.0
4.7 4.7 4.7 4.6 4.6 4.3 4.0
2.0
1.0
5.0 4.9 4.9 4.8 4.6 4.3 4.0
5.0
4.0
5.3 5.3 5.0 4.8 4.7 4.3 4.0
7.0
6.0
5.5 5.3 5.0 4.8 4.7 4.3 4.0
9.0
7.8
5.7 5.3 5.0 4.8 4.7 4.3 4.0
12.0
10.6
5.7 5.3 5.0 4.8 4.7 4.3 4.0
15.0
13.5
5.7 5.3 5.0 4.8 4.7 4.3 4.0
Outdoor Temperature
Indoor temperature
16°CDB 18°CDB 20°CDB 21°CDB 22°CDB 24°CDB 26°CDB
(°CDB)
(°CWB) TC TC TC TC TC TC TC
-19.3
-20.0
2.1 2.1 2.1 2 .1 2.1 2 .1 2.0
-15.0
-16.0
2.4 2.4 2.4 2.4 2.4 2.4 2.4
-12.0
-13.0
2.7 2.7 2.7 2.6 2.6 2.6 2.6
-9.0
-10.0
2.9 2.9 2.9 2.9 2.9 2.9 2.9
-7.0
-8.0
3.1 3.1 3.1 3 .1 3.1 3.1 3.0
-5.0
-6.0
3.3 3.3 3.3 3.3 3.3 3.2 3.1
-3.0
-4.0
3.5 3.5 3.5 3.4 3.4 3.4 3.2
-1.0
-2.0
3.7 3.7 3.6 3.6 3.6 3.4 3.2
0.0
-1.0
3.8 3.7 3.7 3.7 3.7 3.4 3.2
2.0
1.0
4.0 3.9 3.9 3.8 3.7 3.4 3.2
5.0
4.0
4.3 4.2 4.0 3.9 3.7 3.5 3.2
7.0
6.0
4.4 4.3 4.0 3.9 3.7 3.5 3.2
9.0
7.8
4.5 4.3 4.0 3.9 3.7 3.5 3.2
12.0
10.6
4.5 4.3 4.0 3.9 3.7 3.5 3.2
15.0
13.5
4.5 4.3 4.0 3.9 3.7 3.5 3.2
