J-II series2-1-4.
SETTINGS LIST

LED105
CODE No.
Setting Mode
LED104
CODE No.
Setting Function
Factory
setting
Remarks
0 0
Pipe length
setting
0 0 Standard (40 to 65m)
l
Pipe length means the length between outdoor
unit and the nearest indoor unit.
0 1 Short (less than 40m)
0 2 Medium (65 to 90m)
0 3 Long 1 (90 to 120m)
0 4 Prohibited
1 0 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
0 2 Prohibited
0 3 Prohibited
1 1
Cooling
capacity shift
0 0 Normal mode
l
0 1 Save energy mode 1
0 2 High power mode 1
0 3 High power mode 2
0 4 Prohibited
1 2
Heating
capacity shift
0 0 Normal mode
l
0 1 Save energy mode
0 2 High power mode 1
0 3 High power mode 2
1 3 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
1 4 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
0 2 Prohibited
0 3 Prohibited
0 4 Prohibited
2 0
Switching
between
batch stop or
emergency stop
0 0 Batch stop
l
This mode selects the pattern of the stop
function to be operated by the external input
terminal (CN134).
•Batch stop: The stop of all indoor units
connected to same refrigerant system due to
input signal coming from CN134.
•Emergency stop: When emergency stop is
actuated, the indoor unit does not accept the
operation command from the remote controller.
On the other hand, when the emergency
stop is released (no input from CN134), the
air conditioner does not return to the original
operation until operate indoor unit by the remote
controller.
0 1 Emergency stop
- (07-77) -
