Fujitsu Airstage J-II User Manual

HEATING CAPACITY
TC : Total Capacity kW.
CAPACITY TABLE HEATING (INDOOR UNIT)8.
COMPACT CASSETTE TYPE8-1.
MODEL : AUXB04GALH

Outdoor Temperature
Indoor temperature
16°CDB 18°CDB 20°CDB 21°CDB 22°CDB 24°CDB 26°CDB
(°CDB) (°CWB) TC TC TC TC TC TC TC
-19.3 -20.0
0.7 0.7 0.7 0.7 0.7 0.7 0.7
-15.0 -16.0 0.8 0.8 0.8 0.8 0.8 0.8 0.8
-12.0 -13.0 0.9 0.9 0.9 0.8 0.8 0.8 0.8
-9.0 -10.0 1.0 1.0 0.9 0.9 0.9 0.9 0.9
-7.0 -8.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
-5.0 -6.0 1.1 1.1 1.1 1.1 1.1 1.1 1.0
-3.0 -4.0 1.1 1.1 1.1 1.1 1.1 1.1 1.0
-1.0 -2.0 1.2 1.2 1.2 1.2 1.2 1.1 1.0
0.0 -1.0 1.2 1.2 1.2 1.2 1.2 1.1 1.0
2.0 1.0 1.3 1.3 1.3 1.3 1.2 1.1 1.0
5.0 4.0 1.4 1.4 1.3 1.3 1.2 1.1 1.0
7.0 6.0 1.4 1.4 1.3 1.3 1.2 1.1 1.0
9.0 7.8 1.5 1.4 1.3 1.3 1.2 1.1 1.0
12.0 10.6 1.5 1.4 1.3 1.3 1.2 1.1 1.0
15.0 13.5
1.5 1.4 1.3 1.3 1.2 1.1 1.0
MODEL : AUXB07GALH

Outdoor Temperature
Indoor temperature
16°CDB 18°CDB 20°CDB 21°CDB 22°CDB 24°CDB 26°CDB
(°CDB) (°CWB) TC TC TC TC TC TC TC
-19.3 -20.0
1.5 1.4 1.4 1.4 1.4 1.4 1.4
-15.0 -16.0 1.7 1.7 1.7 1.7 1.7 1.7 1.7
-12.0 -13.0 1.9 1.9 1.9 1.8 1.8 1.8 1.8
-9.0 -10.0 2 .1 2.1 2.0 2.0 2.0 2.0 2.0
-7.0 -8.0 2.2 2.2 2.2 2.2 2.2 2.1 2.1
-5.0 -6.0 2.3 2.3 2.3 2.3 2.3 2.3 2.2
-3.0 -4.0 2.4 2.4 2.4 2.4 2.4 2.4 2.2
-1.0 -2.0 2.6 2.6 2.5 2.5 2.5 2.4 2.2
0.0 -1.0 2.6 2.6 2.6 2.6 2.6 2.4 2.2
2.0 1.0 2.8 2.8 2.7 2.7 2.6 2.4 2.2
5.0 4.0 3.0 3.0 2.8 2.7 2.6 2.4 2.2
7.0 6.0 3 .1 3.0 2.8 2.7 2.6 2.4 2.2
9.0 7.8 3.2 3.0 2.8 2.7 2.6 2.4 2.2
12.0 10.6 3.2 3.0 2.8 2.7 2.6 2.4 2.2
15.0 13.5
3.2 3.0 2.8 2.7 2.6 2.4 2.2
MODEL : AUXB09GALH

Outdoor Temperature
Indoor temperature
16°CDB 18°CDB 20°CDB 21°CDB 22°CDB 24°CDB 26°CDB
(°CDB) (°CWB) TC TC TC TC TC TC TC
-19.3 -20.0
1.7 1.7 1.7 1.7 1.6 1.6 1.6
-15.0 -16.0 1.9 1.9 1.9 1.9 1.9 1.9 1.9
-12.0 -13.0 2.1 2.1 2.1 2 .1 2.1 2 .1 2.1
-9.0 -10.0 2.4 2.3 2.3 2.3 2.3 2.3 2.3
-7.0 -8.0 2.5 2.5 2.5 2.5 2.5 2.4 2.4
-5.0 -6.0 2.6 2.6 2.6 2.6 2.6 2.6 2.5
-3.0 -4.0 2.8 2.8 2.8 2.8 2.7 2.7 2.5
-1.0 -2.0 2.9 2.9 2.9 2.9 2.9 2.7 2.5
0.0 -1.0 3.0 3.0 3.0 3.0 3.0 2.7 2.5
2.0 1.0 3.2 3.1 3 .1 3 .1 3.0 2.8 2.5
5.0 4.0 3.4 3.4 3.2 3.1 3.0 2.8 2.6
7.0 6.0 3.5 3.4 3.2 3 .1 3.0 2.8 2.6
9.0 7.8 3.6 3.4 3.2 3 .1 3.0 2.8 2.6
12.0 10.6 3.6 3.4 3.2 3.1 3.0 2.8 2.6
15.0 13.5
3.6 3.4 3.2 3.1 3.0 2.8 2.6
MODEL : AUXB12GALH

Outdoor Temperature
Indoor temperature
16°CDB 18°CDB 20°CDB 21°CDB 22°CDB 24°CDB 26°CDB
(°CDB) (°CWB) TC TC TC TC TC TC TC
-19.3 -20.0
2.1 2.1 2.1 2 .1 2.1 2 .1 2.1
-15.0 -16.0 2.5 2.5 2.5 2.4 2.4 2.4 2.4
-12.0 -13.0 2.7 2.7 2.7 2.7 2.7 2.7 2.7
-9.0 -10.0 3.0 3.0 3.0 3.0 3.0 3.0 2.9
-7.0 -8.0 3.2 3.2 3.2 3.2 3.1 3 .1 3.1
-5.0 -6.0 3.4 3.4 3.4 3.3 3.3 3.3 3.2
-3.0 -4.0 3.6 3.6 3.5 3.5 3.5 3.5 3.2
-1.0 -2.0 3.8 3.7 3.7 3.7 3.7 3.5 3.2
0.0 -1.0 3.9 3.8 3.8 3.8 3.8 3.5 3.2
2.0 1.0 4.1 4.0 4.0 3.9 3.8 3.5 3.3
5.0 4.0 4.4 4.3 4.1 4.0 3.8 3.6 3.3
7.0 6.0 4.5 4.4 4.1 4.0 3.8 3.6 3.3
9.0 7.8 4.6 4.4 4.1 4.0 3.8 3.6 3.3
12.0 10.6 4.6 4.4 4.1 4.0 3.8 3.6 3.3
15.0 13.5
4.6 4.4 4.1 4.0 3.8 3.6 3.3
- (02 - 44) -
