Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

▶
With the label facing up, insert the iRMC microSD card into the microSD
card slot (1) until it locks in place (2).
The onboard position of the microSD card slot can be found in
"Connectors and indicators on the system board" on page 342.
Concluding steps
▶
Install the riser module 1, see "Installing a riser module" on page
61
.
▶
"Installing the air duct" on page 64.
▶
"Reassembling" on page 52.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 58.
15.5.3 Removing the iRMC microSD card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Shutting down the server" on page 45
.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
▶
"Removing the air duct" on page 63.
▶
Remove the riser module 1, see "Removing a riser module" on page 59.
System board and components
RX1330 M4 Upgrade and Maintenance Manual 307

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
