Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

▶
Follow the on-screen instructions to install the ESXi. When the installation is
complete, you will be asked to reboot the server.
▶
While the server is rebooting, enter the BIOS setup menu again and select
the M.2 SSD as primary boot device.
The installation of the ESXi to the M.2 SSD is complete.
For more information on how to access the BIOS and modify settings,
see the corresponding BIOS Setup Utility reference manual.
The M.2 SSD can be used only for boot device. Do not use VMFS on
the M.2 SSD because of not meeting required endurance. For more
information, see the VMware Knowledge Base 2145210.
https://kb.vmware.com/s/article/2145210
For Japan
In order to setup the ESXi, see the corresponding version of the
"VMware vSphere Software Description" from the following URL and
reinstall ESXi to the M.2 SSD.
https://jp.fujitsu.com/platform/server/primergy/software/vmware/manual/
15.6.2 Removing an M.2 SSD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
– Hexagon screw driver (for moving the screw to another hexagon
standoff)
Preliminary steps
▶
"Shutting down the server" on page 45
.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
System board and components
314 Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
