8.8 Drive bays
HDD bay configuration Front:
– up to 12x 3.5-inch HDD
– up to 24x 2.5-inch HDD/SSD
– up to 64x EDSFF
Rear:
– up to 4/6x HDD/SSD/PCIe SSD
Accessible drive bay
(not on 12x 3.5-inch
HDDs, 24x 2.5-inch
HDD/SSD and 64x
EDSFF SSD version)
1 x 5.25/0.5-inch for ODD drive
8.9 Dimension/Weight
Rack (W x D x H) 482.5 mm (bezel) / 435 mm (body) x 800 mm x
86.9 mm
Height unit rack 2 HU
Installation depth in rack 843.6 mm
Weight 15 - 32 kg
Weight notes Weight may vary depending on actual configuration
Rack mounting kit 3.93 kg (Rack mounting kit as option)
8.10 Ventilation clearance
There must be a clearance of at least 200 mm in front of and behind the server
to ensure adequate ventilation of the subsystem.
Technical data
110 Operating Manual RX2540 M6
