Fujitsu PRIMERGY RX2540 M6

Electrical data: 2200 W Platinum
(P/N: S261
13-E646-V50-1 / DPS-2200AB-14A)
Rated voltage range 100 V - 127 V / 200 V - 220 V / 220 V - 240 V
Frequency 50 Hz - 60 Hz
Max. rated current 12.5 A / 11.3 A / 14 A
DC output 100 V - 127 V (1000 W max.)
200
V - 220 V (2000 W max.)
220 V - 240 V (2200 W max.)
Active power max. (AC
input)
2544 W
Apparent power max. 230 V : 2570 VA
100 V : 1252 VA
Heat dissipation 9158.4 KJ/h (8680.4 BTU/h)
Main power fuse 16 A
Protection class I
8.14 Electrical values of the DC PSU -48 V
Electrical data: 1300 W -48 V DC
(P/N: S261
13-E647-V50-1 / DPS-1300AB-28 A)
Rated voltage range -48 V - -60 V
Frequency DC
Max. rated current (DC
input)
37 A max.
Active power max. (DC
input)
1560 W
Apparent power max. N/A
DC output 1300 W max.
Heat dissipation 5616 KJ/h (5322.9 BTU/h)
Technical data
RX2540 M6 Operating Manual 115
