Main power fuse 16 A
Protection class I
8.15 Electrical values of the HVDC PSU 380 V
Electrical data: 1600 W HVDC PSU 380
V
(P/N: S26113-E631-V60-1 / DD-2162J)
Rated voltage range 200 V - 380 V
Frequency DC
Max. rated current (DC
input)
10 A
Active power max. (DC
input)
1800 W
Apparent power max. N/A
DC output 1600 W max.
Heat dissipation 6480 KJ/h (6141.8 BTU/h)
Main power fuse 16 A
Protection class I
8.16 Electrical values of the system
Electrical data: System
500 W Platinum
Rated voltage range 100 V - 240 V
Frequency 50 Hz / 60 Hz
Max. rated current 6.0 A - 2.9 A (x2)
Technical data
116 Operating Manual RX2540 M6
