Fujitsu PRIMERGY RX2540 M6

8.13 Electrical values of the AC PSUs
Electrical data: 500 W Platinum
(P/N: S261
13-E627-V50-1 / DPS-500AB-48A)
Rated voltage range 100 V - 240 V
Frequency 47 Hz - 63 Hz
Max. rated current 6.5 A
DC output 500 W max.
Active power max. (AC
input)
613 W
Apparent power max. 230 V : 600 VA
100 V : 620 V
A
Heat dissipation 2206.8 KJ/h (2091.6 BTU/h)
Main power fuse 16 A
Protection class I
Electrical data: 500 W Platinum
(P/N: S261
13-E627-V70-1 / S19-500P1A)
Rated voltage range 100 V - 240 V
Frequency 50 / 60 Hz
Max. rated current 6.0 A - 2.9 A
DC output 500 W max.
Active power max. (AC
input)
613 W
Apparent power max. 230 V : 600 VA
100
V : 620 VA
Heat dissipation 2206.8 KJ/h (2091.6 BTU/h)
Main power fuse 16 A
Protection class I
Technical data
112 Operating Manual RX2540 M6
