Insert the EDSFF SSD module into a drive bay and carefully push back as
far as it will go (1).
▶
Close the locking lever to lock the EDSFF SSD module in place (2).
6.6
Installing a second PSU
Removing the dummy cover
Figure 42: Removing the dummy cover
▶
Press in on both release latches (1) and remove the dummy cover (2).
CAUTION
▶
Keep the dummy cover for future use.
▶
If you remove a PSU and do not immediately replace it with a new
one, a dummy cover must be installed in the bay again to comply
with applicable EMC regulations and satisfy cooling requirements.
Operation
RX2540 M6 Operating Manual 93
