Configuring the RAID array, see the documentation of the RAID
controller, used in your configuration, see "List of documents" on
page 16.
6.5 Installing EDSFF SSD modules
Removing an EDSFF dummy module
Figure 39: Removing an EDSFF dummy module
▶
Press both tabs together (1) and pull the dummy module out of its bay
(2).
CAUTION
▶
Keep the dummy module for future use.
▶
Always replace dummy modules into unused HDD/SSD bays to
comply with applicable EMC regulations and satisfy cooling
requirements.
Operation
RX2540 M6 Operating Manual 91
