Error indicator (2)
Status Description
off No HDD/SSD error detected.
orange on An HDD/SSD error has been detected.
Possible causes:
–
The drive is defective and needs replacing.
– A RAID rebuild process has failed.
– The HDD/SSD module has not been inserted correctly.
flashing orange
slowly
HDD/SSD RAID rebuild is in progress. Data is being
restored after replacing a drive that has been combined
into a RAID array
.
3.3.2 Server rear
3.3.2.1
Connectors on the server rear
Figure 16: Connectors on the server rear
1 VGA connector
2
Serial interface connector
3 Shared LAN connector (LAN1)
4 Management LAN connector
5 USB 3.0 connectors (2x)
Product description
RX2540 M6 Operating Manual 39
