Status Description
off Data traffic at a transfer rate of 10 Mbit/s.
Indication of LAN connection supporting Energy Efficient Ethernet (EEE
mode)
T
o configure the EEE mode, it is necessary that an add-in LAN card supports
this mode and the connected switch supports this mode as well.
LAN link/transfer indicator (1)
Status Description
short flashing green 3x, then off A LAN connection has been established
(1 Gbit or 100 Mbit) and EEE mode is
active.
Table 2: LAN indicators if EEE mode is active
LAN speed indicator (2)
Status Description
short flashing yellow 1x, then 2
seconds of
f
green off
Data traffic at a transfer rate of 1 Gbit/s.
short flashing green 1x, then 2
seconds off
yellow off
Data traffic at a transfer rate of 100 Mbit/s.
Table 3: LAN indicators if EEE mode is active
Product description
44 Operating Manual RX2540 M6
