Fujitsu PRIMERGY TX1310 M5

Figure 56: Installing the rear fan
▶
Lead the loose ends of the rubber rivets through the four screw holes on the
new rear fan.
▶
Pull tight until the expanding plug on the rubber rivet engages with the fan
(see close-up).
Ensure that the expanding plugs on all four rubber rivets are securely
seated on the fan.
Fans
102 Upgrade and Maintenance Manual TX1310 M5
