Figure 58: Connecting the rear fan cable
▶
Connect the rear fan cable to system board connector "Fan2 (SYS)".
▶
Install the heat sink, see "Installing the heat sink" on page
146
.
Concluding steps
▶
"Installing the top HDD cage" on page 52.
▶
"Reassembling" on page 50.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57
▶
"Installing the bay cover" on page 58
▶
"Locking the server" on page 59
Fans
104 Upgrade and Maintenance Manual TX1310 M5
