Removing the slot cover
Figure 69: Removing the slot cover
▶
Open the slot cover clamp (1).
▶
Remove the desired slot cover (2).
CAUTION
▶
Keep the slot cover for future use.
▶
If the expansion card is removed and not replaced with a new one,
the slot cover must be reinstalled due to cooling, to comply with
applicable EMC regulations and to protect against fire.
Expansion cards
TX1310 M5 Upgrade and Maintenance Manual 117
