Installing the ODD
Figure 105: Installing the ODD
▶
While pressing the fixation plate against the ODD, insert the ODD into
accessible drive bay 1 and push until it is firmly seated in its connector on
the ODD back plate.
Since the ODD is connected to the ODD back plate, no further cable
connection is necessary.
Concluding steps
▶
"Reassembling" on page 50
.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
▶
"Installing the bay cover" on page 58.
▶
"Locking the server" on page 59.
▶
"Reconfiguring the backup software solution" on page 64.
▶
"Resuming BitLocker functionality" on page 68.
Accessible drives
TX1310 M5 Upgrade and Maintenance Manual 161
