"Disconnecting the power cord" on page 42
.
▶
"Getting access to the component" on page 43.
▶
"Removing the top HDD cage" on page 46.
Removing the standard PSU
▶
Push the backup drive somewhat to the front to get more space, see
"Removing the RDX backup drive" on page 169.
Figure 31: Disconnecting the power cable
▶
Disconnect the power cable from system board connector "PWR1".
Power supply unit (PSU)
74 Upgrade and Maintenance Manual TX1310 M5
