Fujitsu PRIMERGY TX1310 M5

Figure 32: Removing the screws
▶
Remove seven screws from the PSU and the chassis (see circles).
Figure 33: Pulling out the system board tray by 1-2 cm
▶
Pull the system board tray out of the chassis by 1-2 cm.
Power supply unit (PSU)
TX1310 M5 Upgrade and Maintenance Manual 75
