Figure 42: Installing a 2.5-inch HDD
▶
Insert the HDD into its drive bay.
▶
Slide the HDD into its drive bay until the Easyrails click in place.
▶
When using a RAID array
, add the additional HDD/SSD to the RAID array.
Configuring the RAID array, refer to the documentation of the RAID
controller, used in your configuration, see "Documentation overview"
on page
22.
Concluding steps
▶
"Reassembling" on page
50
.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
▶
"Installing the bay cover" on page 58.
▶
"Locking the server" on page 59.
Hard disk drives (HDD)
TX1310 M5 Upgrade and Maintenance Manual 85
