CAUTION
All HDD/SSD modules (drives) must be uniquely identified so that they
can be reinstalled in their original bays later. If this is not done, existing
data can be lost.
Preliminary steps
▶
"Unlocking the server" on page 39
▶
"Removing the bay cover" on page
40
▶
"Shutting down the server" on page 41
▶
"Disconnecting the power cord" on page 42
▶
"Getting access to the component" on page 43
Removing the defective 3.5-inch HDD
▶
Remove the HDD, see "Removing a 3.5-inch HDD" on page 94.
Installing the new 3.5-inch HDD
▶
Install the HDD, see "Installing a 3.5-inch HDD" on page 90.
Concluding steps
▶
"Reassembling" on page 50
▶
"Connecting the power cord" on page 56
▶
"Switching on the server" on page 57
▶
"Installing the bay cover" on page 58
▶
"Locking the server" on page 59
▶
"Performing a RAID array rebuild" on page 69
Hard disk drives (HDD)
96 Upgrade and Maintenance Manual TX1310 M5
