Changing modules
3 Close the LCD panel.
4 Disconnect your notebook from the optional port replicator (see
“Disconnecting from the port replicator” on page 90).
5 Turn your notebook over so the bottom is facing up.
6 Remove the security screw if your notebook has one.
7 Slide the bay module release latch. The module moves out slightly.
8 Slide the bay module out.
9 Firmly push the new bay module straight into the bay until the
latches click into place.
10 Reinstall the security screw if your notebook has one.
11 Turn your notebook over.
12 Reconnect the optional port replicator.
13 Open the LCD panel.
Security screw
