Flow specifications
Alternate O2
Minimum flow 500 ml/min to 700 ml/min
Maximum flow 10 l/min to 13 l/min
Indicator Flow tube
Indicator accuracy +/- 5% full scale
Fresh gas
Flow range 0 and 200 ml/min to 15 l/min
Minimum total flow O2 and balance gas is
200 ml/min
Total flow accuracy +/- 10% or +/- 40 ml/min of setting
(whichever is larger)
O2 flow accuracy +/- 5% or +/- 20 ml/min of setting (whichever
is larger)
Balance gas flow accuracy +/- 5% or +/- 20 ml/min of setting (whichever
is larger) Air/N2O
O2 concentration range 21%, 25% to 100%
O2 concentration accuracy +/- 2.5% of setting for total flow of greater
than or equal to 1 l/min and less than or
equal to 15 l/min
+/- 5% of setting for total flow of greater than
or equal to 0.4 l/min and less than 1 l/min
+/- 6.5% of setting for total flow of greater
than or equal to 0.2 l/min and less than 0.4
l/min
Electronic mixer response
time
500 ms (10% to 90% flow step)
Compensation Temperature and atmospheric pressure
compensated to standard conditions of 20°C
and 101.3 kPa (14.7 psi)
Hypoxic guard Electronic
Note: Leakage from one gas inlet to another gas inlet is less than 10 ml per
hour.
Note: The stated flow accuracy may not be met for total flows between 200
and 400 ml/min. The total flow will maintain a minimum of 21% O2.
Aisys CS²
11-12 2067226-001
