Airway module specifications
Use only airway modules that have anesthetic agent monitoring and
O2 monitoring on this system. The following modules can be used on
this system:
•
E-series: E-CAiO, E-CAiOV, E-CAiOVX (software version 4.5
and above)
• M-series: M-CAiO, M-CAiOV, M-CAiOVX (software version 3.2
and above)
• CARESCAPE series: E-sCAiO and E-sCAiOV
Gas specifications for E-, M-series modules
.
E- and M-series
Airway humidity 0 to 100% condensing
Sampling delay 2.5 seconds typical with a 3 m sampling line
Total system response time 2.9 seconds typical with a 3 m sampling line, including sampling delay and rise time
Warm-up time 2 minutes for operation with CO2, O2, and N2O
5 minutes for operation of anesthetic agents
30 minutes for full specifications
Respiration rate 4 to 60 breaths/min
Diversion flow 200 ml/min +/- 20 ml/min
Airway pressure -20 cmH2O to 100 cmH2O
.
E- and M-series airway modules: Accuracy under different conditions
Ambient temperature: 10 to 40°C
Ambient pressure: 500 to 800 mmHg, +/- 50 mmHg of calibration
Ambient humidity: 10 to 98% RH, +/- 20% RH of calibration
Automatic compensation for ambient pressure
Full module accuracy for Respiration rate of 4 to 35 breaths/min
During warm-up 10 to 30 minutes, under normal
conditions
During warm-up 2 to 10 minutes (anesthetic
agents 5 to 10 minutes), under normal
conditions
CO2 +/- (0.3 vol% + 4% of reading) +/- (0.4 vol% + 7% of reading)
O2 +/- (2 vol% + 2% of reading) +/- (3 vol% + 3% of reading)
N2O +/- (3 vol% + 3% of reading) +/- (3 vol% + 5% of reading)
Hal, Enf, Iso,
Sev, Des
+/- (0.2 vol% + 10% of reading) +/- (0.3 vol% + 10% of reading)
11 Specifications and theory of operation
2067226-001 11-19
