Passive scavenging
Negative pressure relief 0.3 cmH2O
Outlet connector 30 mm male taper ISO
Active scavenging
Disposal system
type
Outlet
connector*
Flow range Pressure
Adjustable DISS EVAC Up to 30 l/min not applicable
High flow, low
vacuum
BSI 30 mm
threaded
50 to 80 l/min not applicable
Low flow, high
vacuum
DISS EVAC 36 +/- 4 l/min 305 mmHg (12
inHg) minimum
vacuum
Low flow, low
vacuum
12.7 mm hose
barb
36 +/- 4 l/min not applicable
Low flow, low
vacuum
25 mm hose barb 40 to 50 l/min not applicable
Low flow, low
vacuum
30 mm ISO taper 40 to 50 l/min not applicable
*Other market-specific connectors may be available.
Particle filter at the outlet has a pore size of 225 microns. All flow data uses
a new filter.
11 Specifications and theory of operation
2067226-001 11-15
