GE auisys cs2 User Manual

0
1000 2000 3000 4000 5000 6000 7000 8000 9000
10000 11000 12000 13000 14000 15000
18-25C
10-35C
AB.60.060
1
3 4
2
+20%, +0.4% v/v
+10%, +0.2% v/v
-10%, -0.2% v/v
-20%, -0.4% v/v
5
1. Accuracy is greater of percent of setting (%) or volumetric percent (%
v/v)
2.
Fresh gas flow ml/min
3. All settings
4. Settings equal to or less than 4.0%
5. Settings equal to or less than 1.6%
Figure 11-16 • Sevoflurane accuracy
Accuracy specifications apply after a period of temperature
stabilization with output averaged at the common gas outlet over the
latter minute of a 2 minute delivery at setting.
For a choice of settings and conditions, inaccuracy is the larger
amount of each specified pair percent setting (%) or volumetric
percent (% v/v). Applicable flow setting is inclusive of the right-hand
boundary.
The effect of the fresh gas composition, back pressure (including
ventilation), and ambient pressure on the agent concentration are
included in the accuracy specifications.
The system delivers the same output in volumetric percent (% v/v)
within the specified altitude range.
For Aladin2 desflurane, if not operating in enhanced temperature
sensing mode, the output accuracy may be reduced.
Note
Note
Note
Note
Note
11 Specifications and theory of operation
2067226-001 11-43
