Setting page views
The table shows the factory default settings for each page view.
.
Default settings for Page view setup
Page 1 Page 2 Page 3 Page 4
Top Paw Paw Paw Off
Middle Flow Flow Off Flow
Bottom CO2 CO2 CO2 CO2
Left Loops Off Loops Off
Middle Left Resp Resp Flow Off
Middle Right Agent Agent Agent Off
Right Gases Gases Gases Gases
Split Screen Paw Spiro Paw None
1. From Super User mode, select System Config.
and then Pages
Setup.
2. Select the page to set up.
3. Select an item to change. Make the change.
Waveform fields can be set to AA, CO2, Flow, Paw, or Off.
Digit fields can be set to Gases, Respiration, Gas supplies,
Flow, Agent, Loops, or Off.
Split screen can be set to None, Trends, Spirometry, Paw,
Compliance, or optional ecoFLOW.
4. Select another item. Make the change.
5. When done, select Back to select another page to set up.
