When electronic level sensing is unavailable for an Aladin cassette,
the agent level unknown symbol shows in the agent settings area of
the screen. In this case, refer to the liquid level indicator.
There are three types of Aladin cassette filler systems. Halothane,
enflurane, and isoflurane use color-coded, keyed fillers. Sevoflurane
cassettes are available with a color-coded, keyed filler or a Quik-Fil
mechanism. The desflurane cassettes have a filling mechanism that
is compatible with Safe-T-Fil desflurane bottles.
Sevoflurane Quik-Fil Aladin cassettes are not available in all
countries.
Anesthetic agent Filling system Color code
Halothane Keyed Red
Enflurane Keyed Orange
Isoflurane Keyed Purple
Sevoflurane Keyed or Quik-Fil Yellow
Desflurane Compatible with Saf-T-Fil Blue
1
23
AB.60.004
4
Figure 13-3 • Aladin cassette for halothane, enflurane, isoflurane,
and sevoflurane with keyed filler system
Note
Aisys CS²
13-4 2067226-001
