GE Dash 4000 Service Manual

Field replaceable units: Replace main unit parts
2000966-542D Dash 3000/4000/5000 7-35
flat end of a pen approximately 1- inch deep and push the CF flash
card eject button as shown.
5. Carefully disconnect the antennas using a pen tip, small screwdriver,
or needle nose pliers.
973A
974A
CF card eject button
942A

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
