GE Dash 4000 Service Manual

Field replaceable units: Replace main unit parts
2000966-542D Dash 3000/4000/5000 7-45
b. Remove the wireless card from the PC card bracket by pressing
the CF card eject button. To press the CF card eject button,
carefully insert the flat end of a pen approximately 1- inch deep
and push the CF flash card eject button as shown.
c. Carefully disconnect the antennas using a pen tip, small
screwdriver, or needle nose pliers.
d. Place the wireless card in a safe place.
4. Remove the DAS assembly according to steps starting on page 7-37.
973A
974A
CF card eject button
942A

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
