GE Dash 4000 Service Manual

Field replaceable units: Recommended checkout
7-54 Dash 3000/4000/5000 2000966-542D
NBP assembly “NBP
calibration” on
page 8-37.
 “Noninvasive blood pressure tests” on page 8-
35.
 “Electrical safety tests” on page 8-4.
Wireless LAN None  “Patient monitor power-up tests” on page 8-21.
 “Network test (option)” on page 8-46.
 “Wireless antenna signal strength test (option)”
on page 8-49.
 “Wireless LAN test (option)” on page 8-52.
Wireless card None  “Wireless antenna signal strength test (option)”
on page 8-49.
 “Wireless LAN test (option)” on page 8-52.
Power supply
assembly
None  “Patient monitor power-up tests” on page 8-21.
 “Wireless antenna signal strength test (option)”
on page 8-49. Use this procedure if the wireless
option is installed.
 “Wireless LAN test (option)” on page 8-52. Use
this procedure if the wireless option is installed.
CPU “End-tidal
CO2 test
(option)” on
page 8-44.
“NBP
calibration” on
page 8-37.
 “Patient monitor power-up tests” on page 8-21.
 “Analog output and defibrillator synchronization
tests” on page 8-40.
 “Graph or print tests (option)” on page 8-44.
 “Display test” on page 8-45.
 “Speaker test” on page 8-46.
 “Network test (option)” on page 8-46.
 “Wireless antenna signal strength test (option)”
on page 8-49. Use this procedure if the wireless
option is installed.
 “Wireless LAN test (option)” on page 8-52. Use
this procedure if the wireless option is installed.
 “TRAM-rac 2A module housing peripheral
device test (option)” on page 8-54.
Writer, writer flex None  “Patient monitor power-up tests” on page 8-21.
 “Graph or print tests (option)” on page 8-44.
 “Wireless antenna signal strength test (option)”
on page 8-49. Use this procedure if the wireless
option is installed.
 “Wireless LAN test (option)” on page 8-52. Use
this procedure if the wireless option is installed.
Recommended calibration, electrical safety tests, and checkout procedures
Replacement
procedure
Calibration
tests
Checkout procedures Electrical safety tests

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
